产品描述
减速电机在6VDC下的参数表
Stage 段数 | Ratio 减速比 | Rated current 额定电流 | Rated speed 额定转速 | Rated torque 额定扭矩 | Max.momentary current 最大瞬间电流 | Max.momentary torque 最大瞬间扭矩 | Weight 重量 | |
| 1 | 4:1 | 1760 mA | 5180 RPM | 9.6 mNm | 2540 mA | 14.4 mNm | ||
| 2 | 16:1 | 1760 mA | 1295 RPM | 30.7 mNm | 2540 mA | 46.1 mNm | ||
| 3 | 64:1 | 1760 mA | 324 RPM | 98.3 mNm | 2540 mA | 147.5 mNm | ||
| 4 | 256:1 | 1690 mA | 82 RPM | 300 mNm | 2410 mA | 450 mNm | ||
| 5 | 1024:1 | 820 mA | 23 RPM | 400 mNm | 1150 mA | 600 mNm | ||
减速电机在12VDC下的参数表
Stage 段数 | Ratio 减速比 | Rated current 额定电流 | Rated speed 额定转速 | Rated torque 额定扭矩 | Max.momentary current 最大瞬间电流 | Max.momentary torque 最大瞬间扭矩 | Weight 重量 | |
| 1 | 4:1 | 880 mA | 5180 RPM | 9.6 mNm | 1270 mA | 14.4 mNm | ||
| 2 | 16:1 | 880 mA | 1295 RPM | 30.7 mNm | 1270 mA | 46.1 mNm | ||
| 3 | 64:1 | 880 mA | 324 RPM | 98.3 mNm | 1270 mA | 147.5 mNm | ||
| 4 | 256:1 | 845 mA | 82 RPM | 300 mNm | 1205 mA | 450 mNm | ||
| 5 | 1024:1 | 410 mA | 23 RPM | 400 mNm | 575 mA | 600 mNm | ||
