减速电机在3VDC下的参数表
Stage 段数 | Ratio 减速比 | Rated current 额定电流 | Rated speed 额定转速 | Rated torque 额定扭矩 | Max.momentary current 最大瞬间电流 | Max.momentary torque 最大瞬间扭矩 | Weight 重量 | |
| 1 | 4.25:1 | 64 mA | 6545 RPM | 0.085 mNm | 85 mA | 0.128 mNm | ||
| 2 | 18.1:1 | 64 mA | 1540 RPM | 0.289 mNm | 85 mA | 0.434 mNm | ||
| 3 | 76.8:1 | 64 mA | 362 RPM | 0.983 mNm | 85 mA | 1.474 mNm | ||
| 4 | 326:1 | 64 mA | 85 RPM | 3.341 mNm | 85 mA | 5.011 mNm | ||
减速电机在4.5VDC下的参数表
Stage 段数 | Ratio 减速比 | Rated current 额定电流 | Rated speed 额定转速 | Rated torque 额定扭矩 | Max.momentary current 最大瞬间电流 | Max.momentary torque 最大瞬间扭矩 | Weight 重量 | |
| 1 | 4.25:1 | 45 mA | 6545 RPM | 0.085 mNm | 60 mA | 0.128 mNm | ||
| 2 | 18.1:1 | 45 mA | 1540 RPM | 0.289 mNm | 60 mA | 0.434 mNm | ||
| 3 | 76.8:1 | 45 mA | 362 RPM | 0.983 mNm | 60 mA | 1.474 mNm | ||
| 4 | 326:1 | 45 mA | 85 RPM | 3.341 mNm | 60 mA | 5.011 mNm | ||
| Gearbox stages | Length of gearbox X | Length of gearmotor L | |
| 齿轮箱段数 | 齿轮箱长 X | 减速电机总成 L | |
| 1 | 6.8 | 18.8 | |
| 2 | 8.9 | 20.9 | |
| 3 | 11 | 23 | |
| 4 | 13.1 | 25.1 | |
